PH橡膠多楔帶設計參數：楔距：1.6mm；帶高：2.6±0.1mm；楔角：40±0.5度；楔根圓角半徑：0.15mm；楔頂圓角半徑：0.3mm；楔高：1.25mm
PH橡膠多楔帶具有一定的耐寒與耐熱性能、耐老化、抗臭氧老化性、耐氣候性，不但耐屈撓性能良好，而且其電絕緣性能、耐化學腐蝕、沖擊彈性較好（在低溫下彈性保持性能較好），有良好的耐油、耐溶劑及化學穩定性，加入短纖維補強可承受較高的橫向壓力，增加帶楔耐壓性能，減少受力后變形。
PH橡膠多楔帶兼有v帶和平帶二者的優點，既有平帶的柔軟、強韌的特點，又有v帶緊湊、高效等優點。
PH橡膠多楔帶主要特點如下：
1.傳動功率大，空間相同時比普通V帶的傳動功卒的高30％。
2.傳動系統結構緊湊，在相同的傳動功率情況下，傳遞裝置所占空間比普通V帶小25％。
3.帶體薄，富有柔軟性，適應帶輪直徑小的傳動，也適應高速傳動，帶速可達40m／s；振動小，發熱少，運轉平穩。
4.耐熱、耐油、耐磨，使用伸長小，壽命長。
龍韻公司生產銷售的PH橡膠多楔帶系列產品，引進國外先進技術和生產設備，產品的主要原材料（如骨架材料、橡膠等）均從國外領先的專業生產公司采購進口。產品已通過國家級技術鑒定，可替換同種型號進口PH橡膠多楔帶。
型 號 | 有效長度 | 型 號 | 有效長度 | 型 號 | 有效長度 |
PH350 | 350.00 | PH952 | 952.00 | PH1725 | 1725.00 |
PH356 | 356.00 | PH955 | 955.00 | PH1730 | 1730.00 |
PH360 | 360.00 | PH958 | 958.00 | PH1735 | 1735.00 |
PH366 | 366.00 | PH965 | 965.00 | PH1740 | 1740.00 |
PH370 | 370.00 | PH966 | 966.00 | PH1751 | 1751.00 |
PH376 | 376.00 | PH970 | 970.00 | PH1766 | 1766.00 |
PH381 | 381.00 | PH978 | 978.00 | PH1783 | 1783.00 |
PH390 | 390.00 | PH981 | 981.00 | PH1790 | 1790.00 |
PH392 | 392.00 | PH986 | 986.00 | PH1812 | 1812.00 |
PH401 | 401.00 | PH991 | 991.00 | PH1855 | 1855.00 |
PH406 | 406.00 | PH996 | 996.00 | PH1861 | 1861.00 |
PH411 | 411.00 | PH1003 | 1003.00 | PH1876 | 1876.00 |
PH416 | 416.00 | PH1008 | 1008.00 | PH1880 | 1880.00 |
PH431 | 431.00 | PH1014 | 1014.00 | PH1892 | 1892.00 |
PH442 | 442.00 | PH1016 | 1016.00 | PH1900 | 1900.00 |
PH446 | 446.00 | PH1020 | 1020.00 | PH1920 | 1920.00 |
PH457 | 457.00 | PH1022 | 1022.00 | PH1941 | 1941.00 |
PH477 | 477.00 | PH1028 | 1028.00 | PH1950 | 1950.00 |
PH482 | 482.00 | PH1032 | 1032.00 | PH1960 | 1960.00 |
PH498 | 498.00 | PH1036 | 1036.00 | PH1997 | 1997.00 |
PH505 | 505.00 | PH1041 | 1041.00 | PH2000 | 2000.00 |
PH508 | 508.00 | PH1046 | 1046.00 | PH2004 | 2004.00 |
PH521 | 521.00 | PH1054 | 1054.00 | PH2016 | 2016.00 |
PH528 | 528.00 | PH1060 | 1060.00 | PH2035 | 2035.00 |
PH533 | 533.00 | PH1067 | 1067.00 | PH2040 | 2040.00 |
PH541 | 541.00 | PH1072 | 1072.00 | PH2050 | 2050.00 |
PH552 | 552.00 | PH1078 | 1078.00 | PH2060 | 2060.00 |
PH559 | 559.00 | PH1080 | 1080.00 | PH2075 | 2075.00 |
PH571 | 571.00 | PH1087 | 1087.00 | PH2096 | 2096.00 |
PH584 | 584.00 | PH1089 | 1089.00 | PH2100 | 2100.00 |
PH594 | 594.00 | PH1092 | 1092.00 | PH2110 | 2110.00 |
PH600 | 600.00 | PH1098 | 1098.00 | PH2124 | 2124.00 |
PH605 | 605.00 | PH1102 | 1102.00 | PH2140 | 2140.00 |
PH606 | 606.00 | PH1106 | 1106.00 | PH2145 | 2145.00 |
PH610 | 610.00 | PH1112 | 1112.00 | PH2210 | 2210.00 |
PH614 | 614.00 | PH1117 | 1117.00 | PH2225 | 2225.00 |
PH620 | 620.00 | PH1124 | 1124.00 | PH2256 | 2256.00 |
PH626 | 626.00 | PH1130 | 1130.00 | PH2267 | 2267.00 |
PH635 | 635.00 | PH1137 | 1137.00 | PH2337 | 2337.00 |
PH638 | 638.00 | PH1144 | 1144.00 | PH2340 | 2340.00 |
PH640 | 640.00 | PH1152 | 1152.00 | PH2576 | 2576.00 |
PH646 | 646.00 | PH1156 | 1156.00 | PH2606 | 2606.00 |
PH651 | 651.00 | PH1166 | 1166.00 | PH2666 | 2666.00 |
PH656 | 656.00 | PH1168 | 1168.00 | PH2756 | 2756.00 |
PH660 | 660.00 | PH1180 | 1180.00 | PH2835 | 2835.00 |
PH666 | 666.00 | PH1185 | 1185.00 | PH2837 | 2837.00 |
PH670 | 670.00 | PH1194 | 1194.00 | PH2846 | 2846.00 |
PH674 | 674.00 | PH1216 | 1216.00 | PH2880 | 2880.00 |
PH685 | 685.00 | PH1220 | 1220.00 | PH2927 | 2927.00 |
PH690 | 690.00 | PH1225 | 1225.00 | PH2941 | 2941.00 |
PH700 | 700.00 | PH1230 | 1230.00 | PH2961 | 2961.00 |
PH711 | 711.00 | PH1235 | 1235.00 | PH3031 | 3031.00 |
PH720 | 720.00 | PH1242 | 1242.00 | PH3087 | 3087.00 |
PH736 | 736.00 | PH1256 | 1256.00 | PH3151 | 3151.00 |
PH740 | 740.00 | PH1270 | 1270.00 | PH3201 | 3201.00 |
PH752 | 752.00 | PH1290 | 1290.00 | PH3417 | 3417.00 |
PH761 | 761.00 | PH1300 | 1300.00 | PH3477 | 3477.00 |
PH766 | 766.00 | PH1315 | 1315.00 | PH3573 | 3575.00 |
PH772 | 772.00 | PH1321 | 1321.00 | PH3599 | 3599.00 |
PH776 | 776.00 | PH1330 | 1330.00 | PH3687 | 3687.00 |
PH787 | 787.00 | PH1337 | 1337.00 | PH4362 | 4362.00 |
PH796 | 796.00 | PH1341 | 1341.00 | PH4457 | 4457.00 |
PH801 | 801.00 | PH1355 | 1355.00 | PH4504 | 4504.00 |
PH806 | 806.00 | PH1394 | 1394.00 | PH4647 | 4647.00 |
PH810 | 810.00 | PH1396 | 1396.00 | PH4808 | 4808.00 |
PH813 | 813.00 | PH1420 | 1420.00 | PH5378 | 5378.00 |
PH816 | 816.00 | PH1435 | 1435.00 | PH5512 | 5512.00 |
PH822 | 822.00 | PH1444 | 1444.00 | PH5927 | 5927.00 |
PH827 | 827.00 | PH1456 | 1456.00 | PH6028 | 6028.00 |
PH830 | 830.00 | PH1460 | 1460.00 | PH6197 | 6197.00 |
PH838 | 838.00 | PH1475 | 1475.00 | PH6277 | 6277.00 |
PH841 | 841.00 | PH1480 | 1480.00 | PH7057 | 7057.00 |
PH846 | 846.00 | PH1488 | 1488.00 | PH7142 | 7142.00 |
PH851 | 851.00 | PH1510 | 1510.00 | ||
PH856 | 856.00 | PH1511 | 1511.00 | ||
PH864 | 864.00 | PH1516 | 1516.00 | ||
PH870 | 870.00 | PH1523 | 1523.00 | ||
PH876 | 876.00 | PH1551 | 1551.00 | ||
PH880 | 880.00 | PH1570 | 1570.00 | ||
PH886 | 886.00 | PH1581 | 1581.00 | ||
PH894 | 894.00 | PH1593 | 1593.00 | ||
PH900 | 900.00 | PH1600 | 1600.00 | ||
PH906 | 906.00 | PH1635 | 1635.00 | ||
PH914 | 914.00 | PH1641 | 1641.00 | ||
PH917 | 917.00 | PH1636 | 1636.00 | ||
PH927 | 927.00 | PH1650 | 1650.00 | ||
PH931 | 931.00 | PH1655 | 1655.00 | ||
PH940 | 940.00 | PH1660 | 1660.00 | ||
PH942 | 942.00 | PH1696 | 1696.00 | ||
PH944 | 944.00 | PH1712 | 1712.00 |
