PK橡膠多楔帶設計參數:楔距:3.56mm;帶厚:4.8±0.3mm;楔角:40度;楔根圓角半徑:0.25mm;楔頂圓角半徑:0.6mm;楔高:2.4±0.2mm
PK橡膠多楔帶具有一定的耐寒與耐熱性能、耐老化、抗臭氧老化性、耐氣候性,不但耐屈撓性能良好,而且其電絕緣性能、耐化學腐蝕、沖擊彈性較好(在低溫下彈性保持性能較好),有良好的耐油、耐溶劑及化學穩定性,加入短纖維補強可承受較高的橫向壓力,增加帶楔耐壓性能,減少受力后變形。
PK橡膠多楔帶兼有v帶和平帶二者的優點,既有平帶的柔軟、強韌的特點,又有v帶緊湊、高效等優點。
PK橡膠多楔帶主要特點如下:
1.傳動功率大,空間相同時比普通V帶的傳動功卒的高30%。
2.傳動系統結構緊湊,在相同的傳動功率情況下,傳遞裝置所占空間比普通V帶小25%。
3.帶體薄,富有柔軟性,適應帶輪直徑小的傳動,也適應高速傳動,帶速可達40m/s;振動小,發熱少,運轉平穩。
4.耐熱、耐油、耐磨,使用伸長小,壽命長。
龍韻公司生產銷售的PK橡膠多楔帶系列產品,引進國外先進技術和生產設備,產品的主要原材料(如骨架材料、橡膠等)均從國外領先的專業生產公司采購進口。產品已通過國家級技術鑒定,可替換同種型號進口PK橡膠多楔帶。
型 號 | 有效長度 | 型 號 | 有效長度 | 型 號 | 有效長度 |
PK520 | 520.00 | PK1070 | 1070.00 | PK1480 | 1480.00 |
PK525 | 525.00 | PK1075 | 1075.00 | PK1485 | 1485.00 |
PK530 | 530.00 | PK1080 | 1080.00 | PK1510 | 1510.00 |
PK535 | 535.00 | PK1090 | 1090.00 | PK1515 | 1515.00 |
PK540 | 540.00 | PK1095 | 1095.00 | PK1520 | 1520.00 |
PK550 | 550.00 | PK1100 | 1100.00 | PK1525 | 1525.00 |
PK555 | 555.00 | PK1105 | 1105.00 | PK1550 | 1550.00 |
PK560 | 560.00 | PK1110 | 1110.00 | PK1565 | 1565.00 |
PK570 | 570.00 | PK1115 | 1115.00 | PK1580 | 1580.00 |
PK585 | 585.00 | PK1120 | 1120.00 | PK1590 | 1590.00 |
PK590 | 590.00 | PK1125 | 1125.00 | PK1600 | 1600.00 |
PK595 | 595.00 | PK1130 | 1130.00 | PK1630 | 1630.00 |
PK600 | 600.00 | PK1135 | 1135.00 | PK1635 | 1635.00 |
PK605 | 605.00 | PK1140 | 1140.00 | PK1640 | 1640.00 |
PK610 | 610.00 | PK1145 | 1145.00 | PK1645 | 1645.00 |
PK615 | 615.00 | PK1150 | 1150.00 | PK1650 | 1650.00 |
PK620 | 620.00 | PK1155 | 1155.00 | PK1655 | 1655.00 |
PK625 | 625.00 | PK1165 | 1165.00 | PK1660 | 1660.00 |
PK630 | 630.00 | PK1170 | 1170.00 | PK1690 | 1690.00 |
PK635 | 635.00 | PK1175 | 1175.00 | PK1695 | 1695.00 |
PK640 | 640.00 | PK1180 | 1180.00 | PK1710 | 1710.00 |
PK650 | 650.00 | PK1185 | 1185.00 | PK1720 | 1720.00 |
PK655 | 655.00 | PK1190 | 1190.00 | PK1725 | 1725.00 |
PK660 | 660.00 | PK1195 | 1195.00 | PK1730 | 1730.00 |
PK665 | 665.00 | PK1215 | 1215.00 | PK1735 | 1735.00 |
PK670 | 670.00 | PK1220 | 1220.00 | PK1740 | 1740.00 |
PK675 | 675.00 | PK1225 | 1225.00 | PK1750 | 1750.00 |
PK680 | 680.00 | PK1230 | 1230.00 | PK1765 | 1765.00 |
PK685 | 685.00 | PK1235 | 1235.00 | PK1780 | 1780.00 |
PK690 | 690.00 | PK1240 | 1240.00 | PK1785 | 1785.00 |
PK695 | 695.00 | PK1255 | 1255.00 | PK1790 | 1790.00 |
PK700 | 700.00 | PK1270 | 1270.00 | PK1810 | 1810.00 |
PK710 | 710.00 | PK1290 | 1290.00 | PK1850 | 1850.00 |
PK715 | 715.00 | PK1300 | 1300.00 | PK1860 | 1860.00 |
PK720 | 720.00 | PK1310 | 1310.00 | PK1875 | 1875.00 |
PK735 | 735.00 | PK1315 | 1315.00 | PK1880 | 1880.00 |
PK740 | 740.00 | PK1320 | 1320.00 | PK1890 | 1890.00 |
PK750 | 750.00 | PK1325 | 1325.00 | PK1900 | 1900.00 |
PK760 | 760.00 | PK1330 | 1330.00 | PK1915 | 1915.00 |
PK765 | 765.00 | PK1335 | 1335.00 | PK1920 | 1920.00 |
PK770 | 770.00 | PK1340 | 1340.00 | PK1940 | 1940.00 |
PK775 | 775.00 | PK1350 | 1350.00 | PK1950 | 1950.00 |
PK780 | 780.00 | PK1355 | 1355.00 | PK1960 | 1960.00 |
PK785 | 785.00 | PK1390 | 1390.00 | PK1995 | 1995.00 |
PK795 | 795.00 | PK1395 | 1395.00 | PK2000 | 2000.00 |
PK800 | 800.00 | PK1420 | 1420.00 | PK1015 | 1015.00 |
PK805 | 805.00 | PK1430 | 1430.00 | PK2030 | 2030.00 |
PK809 | 809.00 | PK1435 | 1435.00 | PK2035 | 2035.00 |
PK810 | 810.00 | PK1440 | 1440.00 | PK2040 | 2040.00 |
PK815 | 815.00 | PK1445 | 1445.00 | PK2050 | 2050.00 |
PK820 | 820.00 | PK1455 | 1455.00 | PK2060 | 2060.00 |
PK825 | 825.00 | PK1460 | 1460.00 | PK2070 | 2070.00 |
PK830 | 830.00 | PK1470 | 1470.00 | PK2095 | 2095.00 |
PK835 | 835.00 | PK1475 | 1475.00 | PK2100 | 2100.00 |
PK840 | 840.00 | PK1480 | 1480.00 | PK2110 | 2110.00 |
PK845 | 845.00 | PK1485 | 1485.00 | PK2120 | 2120.00 |
PK850 | 850.00 | PK1510 | 1510.00 | PK2140 | 2140.00 |
PK855 | 855.00 | PK1515 | 1515.00 | PK2145 | 2145.00 |
PK860 | 860.00 | PK1520 | 1520.00 | PK2205 | 2205.00 |
PK865 | 865.00 | PK1525 | 1525.00 | PK2210 | 2210.00 |
PK870 | 870.00 | PK1550 | 1550.00 | PK2225 | 2225.00 |
PK875 | 875.00 | PK1565 | 1565.00 | PK2255 | 2255.00 |
PK880 | 880.00 | PK1580 | 1580.00 | PK2265 | 2265.00 |
PK885 | 885.00 | PK1590 | 1590.00 | PK2285 | 2285.00 |
PK890 | 890.00 | PK1600 | 1600.00 | PK2340 | 2340.00 |
PK895 | 895.00 | PK1630 | 1630.00 | PK2360 | 2360.00 |
PK900 | 900.00 | PK1635 | 1635.00 | PK2375 | 2375.00 |
PK905 | 905.00 | PK1640 | 1640.00 | PK2400 | 2400.00 |
PK910 | 910.00 | PK1645 | 1645.00 | PK2460 | 2460.00 |
PK915 | 915.00 | PK1650 | 1650.00 | PK2495 | 2495.00 |
PK920 | 920.00 | PK1655 | 1655.00 | PK2585 | 2585.00 |
PK925 | 925.00 | PK1660 | 1660.00 | PK2665 | 2665.00 |
PK930 | 930.00 | PK1690 | 1690.00 | PK2835 | 2835.00 |
PK935 | 935.00 | PK1695 | 1695.00 | PK2875 | 2875.00 |
PK940 | 940.00 | PK1710 | 1710.00 | PK2925 | 2925.00 |
PK945 | 945.00 | PK1720 | 1720.00 | PK2955 | 2955.00 |
PK950 | 950.00 | PK1725 | 1725.00 | PK3085 | 3085.00 |
PK955 | 955.00 | PK1730 | 1730.00 | PK3180 | 3180.00 |
PK960 | 960.00 | PK1735 | 1735.00 | PK3194 | 3194.00 |
PK965 | 965.00 | PK1740 | 1740.00 | PK3475 | 3475.00 |
PK970 | 970.00 | PK1750 | 1750.00 | PK3570 | 3570.00 |
PK975 | 975.00 | PK1765 | 1765.00 | PK3685 | 3685.00 |
PK980 | 980.00 | PK1780 | 1780.00 | PK4356 | 4356.00 |
PK985 | 985.00 | PK1325 | 1325.00 | PK4451 | 4451.00 |
PK990 | 990.00 | PK1330 | 1330.00 | PK4498 | 4498.00 |
PK995 | 995.00 | PK1335 | 1335.00 | PK4641 | 4641.00 |
PK1000 | 1000.00 | PK1340 | 1340.00 | PK4802 | 4802.00 |
PK1005 | 1005.00 | PK1350 | 1350.00 | PK5372 | 5372.00 |
PK1010 | 1010.00 | PK1355 | 1355.00 | PK5506 | 5506.00 |
PK1015 | 1015.00 | PK1390 | 1390.00 | PK5921 | 5921.00 |
PK1020 | 1020.00 | PK1395 | 1395.00 | PK6022 | 6022.00 |
PK1025 | 1025.00 | PK1420 | 1420.00 | PK6191 | 6191.00 |
PK1030 | 1030.00 | PK1430 | 1430.00 | PK6271 | 6271.00 |
PK1035 | 1035.00 | PK1435 | 1435.00 | PK7051 | 7051.00 |
PK1040 | 1040.00 | PK1440 | 1440.00 | PK7136 | 7136.00 |
PK1045 | 1045.00 | PK1445 | 1445.00 | ||
PK1050 | 1050.00 | PK1455 | 1455.00 | ||
PK1055 | 1055.00 | PK1460 | 1460.00 | ||
PK1060 | 1060.00 | PK1470 | 1470.00 | ||
PK1065 | 1065.00 | PK1475 | 1475.00 |
